Subwoofer 12" 2500w DB Drive WDX12G2R.4
WDX12G2R.4 : 12 in. Dual 4-Ohm Subwoofer
- Dynamic Power Handling: 2500 Watts
- Nominal Power Handling: 1250 Watts
- Impedance: Dual 4Ω Voice Coil
- Resonant Frequency (fs): 33.597 Hz
- D.C. Voice Coil Resistance (Re): 2 x 3.2Ω
- Mechanical Quality Factor (Qms): 4.413
- Electrical Quality Factor (Qes): 1.253
- Total Quality Factor (Qts): 0.976
- Equivalent Air Volume (Vas): 22.153 L
- Mechanical Compliance of Suspension (CMS): 57.973 mm/N
- Mass of Diaphragm/Coil (Mms): 387.090 g
- Force Factor (BL): 20.429
- Sound Pressure Level (SPL): 80.1 dB
- 3.0″ Anodized aluminum high temperature voice coil
- Non-Pressed paper cone
- Double-stitched reinforced foam surround
- Dual poly-cotton dampeners
- Die-cast aluminum vented basket
- Rubber gasket trim ring
- Large gauge compression terminals
- Protective magnet cover
