Amplificador DS18 GFX-5K1 PRO Full-Range Class D 1-Channel Monoblock Amplifier 5000 Watts Rms 1-Ohm
| Model No. |
GFX-5K1 |
| Power @ 1 ohms (14.4V) |
5000W |
| Power @ 2 ohms (14.4V) |
3500W |
| Minimum Speaker Load |
1 OHM |
| THD |
1% |
| Input Sensitivity |
0.5-8V |
| Hi Pass Crossover (12dB/Oct) |
15Hz-2KHZ |
| Lo Pass Crossover (12dB/Oct) |
50Hz-20KHZ |
| Frequency Response |
15Hz-20KHZ |
| Bass Boost |
0-12dB |
| Bass Boost Frequency |
35Hz-70Hz |
| Working Voltage |
9-15V |
| Input Terminal Size |
1/0AWG |
| Output Terminal Size |
8 AWG |
| Dimensions (mm) |
291 x 236 x 72 |
